| Place of Origin: | Jinan city,Shandong province,China |
| Brand Name: | ZW |
| Certification: | ISO9001:2008 |
| Model Number: | 45#,60Mn B2,B3,B6 |
| Minimum Order Quantity: | 25 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | container bags ,steel drum |
| Delivery Time: | 1-3 weeks after the advance |
| Supply Ability: | Annual output 50000 tons |
| Product Name: | Hot Rolled Steel Balls 20mm-150mm Casting Services For Autogenous Ball Mills For Mining | Application: | Mining,mine,cement Plant,power Plant |
|---|---|---|---|
| Grade: | YG15/YG12/YG13/YG13C/YG18C/YG20C/YG22C/YG25/YG25C | Shape: | Ball |
| Sample: | Free | Packing: | Degrease,Steel Drums Or Bags |
| Warranty: | One Year | Leading Time: | According To The Contract |
| Highlight: | Mining Hot Rolled Steel Balls |
||
Hot Rolled Steel Balls 20mm-150mm Casting Services for Autogenous Ball Mills for Mining
The Forged Grinding Ball is a high-quality product designed for various grinding applications in industries such as mining, cement plants, power stations, and chemical industries. Known by various names such as Grinding Steel Ball, Forged Iron Ball, and Hot Rolled Grinding Ball, this product offers exceptional performance and durability.
Characteristics of forged steel balls: a. The interior is tight. Since it is forged from round steel, it avoids defects caused by
the process in the cast state. The internal density is high and the fine grain size is high, which enhances the ball's drop
resistance and impact toughness, thereby reducing the ball's breakage. rate; the impact toughness is 4-5 times that of cast balls.
This technical parameter determines that the breakage rate of forged balls is much lower than that of cast balls; b. Both dry and
wet grinding are possible. Because high-quality alloy steel is heated at high temperature in a heating furnace to obtain
austenite, martensite is obtained through forging, rotary cutting, rolling, and quenching. After tempering, stress relief and
decomposition of residues are achieved. Austenite changes the matrix structure, thereby greatly improving its corrosion resistance
and significantly enhancing its hardness and toughness; c. In view of the situation where mines are mostly wet grinding, this
steel ball is suitable for the working conditions. d. Cast balls are "heat-resistant" balls (suitable for dry grinding), and
forged balls are "corrosion-resistant" balls (suitable for wet grinding). Most forged balls are used internationally.
| Material | Chemical Elements | |||||
| C | Si | Mn | P/S | Cr | Hardness (HRC) | |
| 45# | 0.42-0.50 | 0.17-0.37 | 0.5-0.8 | <0.035 | <0.25 | 60-65 |
| 60MN | 0.55-0.65 | 0.17-0.37 | 0.7-1.0 | <0.04 | <0.25 | 58-63 |
| B2 | 0.72-0.85 | 0.17-0.37 | 0.7-1.0 | <0.04 | 0.4-0.6 | 55-58 |
| B3 | 0.58-0.66 | 1.3-1.9 | 0.65-0.8 | <0.025 | 0.7-0.9 |
56-65 |
| B6 | 0.97-1.03 | 0.2-0.3 | 1.0-1.1 | <0.025 | 0.5-0.6 | 61-65 |
|
Material
|
25mm-50mm HRC |
60mm-90mm HRC |
100mm-125mm HRC
|
130-150mm HRC |
||||
| Surface | Core | Surface | Core | Surface | Core | Surface | Core | |
| C45 | 55-58 | 55-58 | 50-68 | 23-30 | 48-52 | 22-26 | 48-52 | 22-25 |
| 60Mn | 58-62 | 55-60 | 58-62 | 30-36 | 57-61 | 26-32 | 57-61 | 26-30 |
| B2 | 60-64 | 58-64 | 57-64 | 45-60 | 55-60 | 38-48 | 55-60 | 38-42 |
| B3 | 62-65 | 60-65 | 60-65 | 58-65 | 56-65 | 50-62 | 56-63 | 50-55 |
| B6 | 62-65 | 60-65 | 61-65 | 58-65 | 60-63 | 50-62 | 61-63 | 50-55 |
1) Traditional Forged
Raw material →Cutting →Heating → Water quenching → Tempering
2) Auto Hot Rolling
Raw material →Hot Rolling Mill → Water Quenching → Tempering
| Testing | Jinan Zhongwei established in 2000, leading manufacturer and exporter of grinding balls in China |
| Production Capacity | Annual output is 50000 tons to 80000 tons |
| Breakage Guarantee | ≤0.5-1.0% |
| Impact | >12 |
| Exported Countries | 20 more countries including UAE, Zambia, South Africa, Peru, Chile, Australia, UK, USD, Turkey |
| Wear Resistance | Better than cast ball with longer service life |
| Impact Toughness | >12 joules |
| Surface Quality | Smooth surface without pouring mouth, sand hole, and ring band |
| Breakage Rate | <0.5% |
| Product Name | Hot Rolled Steel Balls 20mm-150mm Casting Services for Autogenous Ball Mills for Mining |
They have great wear resistance, difficult deformation and less broken, uniform hardness distribution, high impact toughness( over 12j/cm2). Mainly suitable for industries such as mining, steel, chemical industry, cement plants, power plants, ball coal machine, semi-automatic ball mills, and ball mills,etc.
inan Zhongwei established in 2000 , we are a leading manufacturer and professional exporter grinding balls in China.
Our company covers an area of 15000 square meters, now we have 150 staff, including 13 technical staff. Annual output is 50000 tons to 80000 tons .
Main products : forged steel ball, cast iron ball ,grinding rod, cylpebs
We have exported to 20 more countries, UAE, Zambia,South Africa, Peru, Chile, Australia, UK, USA, Turkey and so on.
Quality control for each production shift (4hours/Shift);
Hardness, chemical elements and impact testing after production for each production shift;
SGS –third party testing before each delivery
Product Packaging:
Each Forged Grinding Ball is carefully packed in individual boxes to ensure safe transportation and handling. The boxes are labeled with product information and specifications for easy identification.
Shipping:
Our Forged Grinding Balls are shipped in sturdy cartons to protect them from damage during transit. We work with trusted shipping partners to ensure timely delivery to our customers.
Q :Are you a manufacturer or a trading company ?
We are a manufactuer specialized in mill ball since 2001
Q :How can I get some samples ?
We are honored to offer you samples for free, but the new clients are expected to pay
the express cost, and the charge will be deducted from the payment for formal order.
Q :Can your factory print or emboss my logo on the goods ?
Yes,we can print or emboss your own logo on the goods or their packing drums.
Q :What's your MOQ of this product?
MOQ is 1 ton ,if less,please check with us firstly.
Q :What's your delivery time?
It is about 15-25 days, if your goods required urgent, please contact us firstly.
