Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine

Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine

  • Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
  • Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
  • Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
  • Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
  • Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine
Product Details:
Place of Origin: CHINA
Brand Name: ZW
Certification: ISO9001:2008 SGS
Model Number: GB/T 17445-2009
Payment & Shipping Terms:
Minimum Order Quantity: 10/tons
Price: Negotiable
Packaging Details: container bags or steel drums
Delivery Time: 7-14 days
Supply Ability: 50000 tons/year
Contact Now
Detailed Product Description
Breakage Guarantee: No Break Heat Treatment: Oil Quenching
Quality System Authentication: ISO9001:2008/SGS TEST REPORT HRC: 58-64
Name: Casting Steel Grinding Balls CR: Cr:16
High Light:

HRC64 Cast Iron Ball

,

Unbreakable Cast Iron Ball

Unbreakable Cast Grinding Media High Quality Cast Iron Balls For Mine


 Process features of cast iron balls:
Moulding process---pouing when the molten iron temoerature reaches 1500 C,using the teoperature difference between moletn iron and the molds.in this way,the ball can achieve internal organization  of grain refinement and be moredense.menanwhile,the carvide is radially arranged .and such carbide is embedded in  the matrix again during  grinding process,forming hatd layer continously,so that the hardness and toughness is maintained to a reasonable range,greatly improving the toughness and hardness of the grinding balls.
Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine 0

Specifications of our products as follows:

                          Type and Chenical Composition of Cast Balls


       Name



Material

                       Chemical Composition
         C Si Mn S/P Cr HRC
Cast ball

special hi-cr

2.0-3.2 <1.0 0.5-2.0 <0.06 >18 58-64

higt-cr


2.0-3.2 <1.0 0.5-1.5 <0.06 >10 58-62


medium-cr

2.0-3.2 <1.0 0.5-1.5 <0.06 ≥5 45-48


low-cr

2.2-3.4 ≤1.2 0.5-1.5 ≤0.06 1.0-1.5 42-46






    Physical property of cast iron balls



  Name



Material

Impact test

AK.j/cm^2

Endurance test times HRC Breakage









Cast ball





special hi-cr ≥4 ≥10000 58-64 <1%
higt-cr ≥3 ≥10000 58-62 <1%
medium-cr ≥3 ≥8000 45-48 <1%
low-cr ≥2 ≥8000 42-46 <1%


5.Package: Steel drums (850kg per drum) or Flexible Container Bags ( 1000kg per bag)
 Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine 1

Container Bag Steel Drum
Net weight 1000kgs for all size balls Ball Size Net Weight
20-30mm 930-1000kgs
40-60mm 900-930kgs
70-90mm 830-880kgs
100mm and above 830-850kgs

Bag: 73×60cm, 1.5kg, 0.252CBM

Drum: 60×90cm, 15-20kg, 0.325CBM

Pallet: Single: 60×60×9cm, 4-6kg; Double:120×60×10cm,12-14kg





.Electric furnace smelting:All cast steel balls are produced by intermediate frequency electric furance .The purity and stability of materials are effectively esured after unform temerature conditioning and twice hot metal purificati0n.



.Assay before furnace :Temperature control is an important and complex process during cast steel ball production.Different tapping temperature and heat temperature are sensitively reflected in the quality of the products.It is requested to master the proper pouring temperature ,mold temperature ,so that can make sure the products achieve a good state of body tisssue during the transition from Liquid to solid states.





Unbreakable Grinding Media HRC64 Cast Iron Ball For Mine 2
